Suzuki King Quad LT-A400 LT-F400 2008-2009 Factory Workshop Manual

Covers 2wd and 4x4 models

This is the same manual your local dealer will use when doing a repair. The manual for the King Quad LT-A400 LT-F400 2008-2009 has detailed illustrations as well as step by step instructions. All pages are printable, so run off what you need and take it with you into the garage or workshop. These manuals are your number one source for repair and service information. They are specifically written for the do-it-yourself as well as the experienced mechanic. Using this repair manual is an inexpensive way to keep your atv working properly. Each manual provides step-by-step instructions based on the complete dis-assembly of the machine. It is this level of detail, along with hundreds of illustrations, that guide the reader through each service and repair procedure.


Topics Covered

Precautions............................................................... 00-i
Precautions ............................................................ 00-1
General Information ................................................... 0-i
General Information ...............................................0A-1
Maintenance and Lubrication.................................0B-1
Service Data...........................................................0C-1
Engine ......................................................................... 1-i
Precautions .............................................................. 1-1
Engine General Information and Diagnosis ...........1A-1
Emission Control Devices ......................................1B-1
Engine Mechanical.................................................1D-1
Engine Lubrication System ....................................1E-1
Fuel System ...........................................................1G-1
Ignition System.......................................................1H-1
Starting System....................................................... 1I-1
Charging System.....................................................1J-1
Exhaust System .....................................................1K-1
Suspension................................................................. 2-i
Precautions .............................................................. 2-1
Suspension General Diagnosis..............................2A-1
Front Suspension ...................................................2B-1
Rear Suspension....................................................2C-1
Wheels and Tires ...................................................2D-1
Driveline / Axle ........................................................... 3-i
Precautions .............................................................. 3-1
Drive Chain / Drive Train / Drive Shaft ...................3A-1
Differential ..............................................................3B-1
Transfer..................................................................3C-1
Propeller Shafts......................................................3D-1
Brake ........................................................................... 4-i
Precautions .............................................................. 4-1
Brake Control System and Diagnosis ....................4A-1
Front Brakes...........................................................4B-1
Rear Brakes ...........................................................4C-1
Parking Brake.........................................................4D-1
Transmission / Transaxle .......................................... 5-i
Precautions .............................................................. 5-1
Automatic Transmission.........................................5A-1
Manual Transmission .............................................5B-1
Clutch .....................................................................5C-1
Steering....................................................................... 6-i
Precautions .............................................................. 6-1
Steering General Diagnosis ...................................6A-1
Steering / Handlebar ..............................................6B-1
Body and Accessories............................................... 9-i
Precautions .............................................................. 9-1
Wiring Systems ......................................................9A-1
Lighting Systems....................................................9B-1
Combination Meter / Fuel Meter / Horn..................9C-1
Exterior Parts .........................................................9D-1
Body Structure .......................................................9E-1
